Site conditions required for efficient powder filling

The guide to powder filling series #5

If site conditions are not managed properly, powder filling can be quite challenging

Powder filling requires management of the powder and the site to ensure successful packaging operations. If not managed properly, powder filling throws up challenges. Powder’s physical properties are influenced by the way they are stored and transported. Constant loose bulk density and maintenance of flow rate are crucial in the performance of the dosing systems.

Therefore, ensuring the right site conditions is crucial for maintaining product quality and operational efficiency. Factors such as bulk density (BD), flow properties, ambient temperature, humidity, conveying methods, power quality, film storage, and cleaning routines all play pivotal roles in achieving successful powder-filling operations.

Here, we delve into each aspect and discuss best practices for ensuring an optimal powder-filling environment. Site conditions can broadly be classified into firstly, powder storage and transportation conditions; and, conditions required for the operation of the packaging equipment.

Powder storage and transportation requirements

Before we delve into the topic let us understand the key requirements to focus on.

Bulk density and flow propertiesthese are key characteristics that directly impact the efficiency and accuracy of powder filling. It is essential to maintain these properties throughout the filling process to prevent issues such as clogging, inconsistent filling, and product wastage.

Ambient temperature and humiditythe filling area should be controlled to ensure that the powder characteristics remain stable. Fluctuations in temperature and humidity can lead to changes in the powder’s flow properties and bulk density, affecting the filling process’ accuracy and efficiency.

Powder storage is crucialthe powders need protection from humidity, sun light, oxygen depending upon their chemistry. The storage bins and or silos need to offer the required protection.

When ready for packing and before transportation, the powders need to be brought to their loose bulk density. The delta between loose and tapped density is normally 20%. Therefore, the powder needs to be blended to loosen up the powder before transportation. Blending also helps even out bulk density variation from different batches or powders from different sources. Large silos must have agitators, and these must be on to ensure the powder does not settle down.

Storage of the powder needs attention. Some of the steps highlighted above may be needed depending on the powder.

It is possible that in some cases the powders are taken up for packing in line. Therefore, the next step to focus is the technology to be used for conveying the product from the manufacturing (storage) area to the packaging units.

Conveying methods

Choosing the right conveying method is crucial for avoiding product breakage and changes in bulk density. The conveying systems need to offer the required protection as well. Let us look at some of the conveying systems used in the industry and look at their pros and cons.

Belt conveyorsThese are normally used for horizontal conveying. These can be open to the atmosphere or can be enclosed to avoid contamination. Popular in non-food applications and also where the product is warm after production and the powder needs cooling. The powder quality will remain constant as long as the atmosphere will have no influence.

Pneumatic conveyors These are enclosed conveyors and are conveyed using air. The air quality should be clean in order not to contaminate the product. These are popular, the only thing to remember is that pneumatic conveyors loosen up the powder therefore the bulk density is affected. Pneumatic conveyors can also help you move the powders vertically.

Cable conveyorsThese are enclosed conveyors where discs attached to a cable at an equal distance move to transport the powder. The disc works like a piston in a cylinder. The biggest advantage of these conveyors is that they can incorporate bends. This will allow you to transport the powder from anywhere to anywhere.

Screw conveyorsBy far the most popular feeding methodology for transporting powders. The powder is transported inside a tube using rotating screws. The conveyor is completely enclosed. Clearance between the screw and tube can be designed to minimize breakage.

Vibratory conveyors These are normally used for conveying short distances in powder applications. The conveyors can induce bulk density variation and product separation.

There are options and when it comes to conveying it is imperative to understand the powder before choosing the right solution.

Let us now look at other important site conditions.

Power quality Your equipment uses sophisticated electronics and expensive servo motors. Ensuring the right power infrastructure is crucial.

Proper earthing and maintenance of earth pitsSeparating power and control electronics lines would be a prudent strategy. Earth to neutral voltage must be minimum. Spike busters and voltage management hardware are crucial.

Maintaining a stable power supply is essential for preventing disruptions in the filling process. Fluctuations in power can lead to downtime and product wastage, so it’s important to invest in reliable power backup systems and voltage stabilizers.

Film storage Proper storage of film is essential for maintaining its quality and integrity. Film should be stored in a clean, dry environment, away from direct sunlight and contaminants. Regular inspections should be conducted to ensure that the film is in good condition and free from any defects that could affect the filling process. Maintaining the core is important in being able to load it onto the packaging machine. The storage area must be close to the filling station.

Cleaning routinesFrequent cleaning of the filling equipment is essential for preventing contamination and maintaining product quality. Cleaning should be done using approved cleaning agents and procedures to ensure that all surfaces are thoroughly cleaned and sanitized.

Spares for the equipmentUnderstanding the consumable spares and their storage will help minimize downtime. Understanding MTBF and main failures should help in designing a proactive preventive maintenance schedule.

Trained manpowerManpower trained in operating and maintaining your equipment is crucial. These need to be managed. Challenges introduced by attrition need to be addressed through proper documentation and training manuals.

In conclusion, ensuring the right site conditions is essential for successful powder-filling operations. By paying attention to factors such as bulk density, flow properties, ambient temperature, humidity, conveying methods, power quality, film storage, and cleaning routines, you can optimize your powder-filling process for maximum efficiency and product quality.
